The rising stem resilient seat gate valve is widely used in pipeline systems for media such as water, steam, and oil. With its resilient sealing structure, it offers good sealing performance, intuitive operation, and easy maintenance. The gate moves perpendicular to the fluid direction. This valve is designed for fully open or fully closed service only and must not be used for throttling or flow regulation.
Exposed Stem: Valve open/closed status can be visually determined by the stem rising height
Double Sealing Surfaces: Wedge-type gate structure with a wedge angle of typically 5°, or 2°52′ for lower temperature media
Resilient Sealing Material: Made of EPDM, NBR or other corrosion-resistant materials for excellent sealing performance
Flange Connection: Easy for pipeline installation and maintenance
|
Advantage |
Description |
|
Good Sealing Performance |
Resilient sealing material effectively prevents leakage, especially suitable for water and gas media |
|
Intuitive Operation |
Exposed stem design allows easy visual status check on site |
|
Corrosion Resistance |
Suitable for corrosive media in water treatment, chemical industry, etc. |
Not suitable for high temperature or high pressure: Resilient sealing materials typically withstand temperatures up to 80°C (depending on material). For high pressure conditions, please select a metal hard seal gate valve.
Avoid particle-laden media: Solid particles may damage the resilient sealing surface. A strainer is recommended when the media contains sand or particles.
1. Project References
With over 19 years of valve manufacturing experience and dual production bases (Tianjin for cast iron, Wenzhou for cast steel), our rising stem resilient seat gate valves have been widely used in:
Municipal water supply projects in Southeast Asia (Philippines, Thailand, etc.)
Industrial piping systems for petrochemical auxiliary facilities in the Middle East
Water treatment and supply projects in Zhejiang, Tianjin, and other regions in China
2. OEM / ODM Customization Services
OEM Services: Valve body color, cast logo, nameplate design, packaging customization
ODM Services: Stem height adjustment, flange drilling standards (ANSI, BS, DIN, GB), EPDM/NBR formula optimization for specific media
Low MOQ: As low as 50 units for logo customization
3. Certifications
ISO 9001:2015
WRAS certified EPDM seat (available upon request – essential for drinking water applications)
Multiple design and utility model patents
4. After-Sales Service
One-year warranty: Free replacement for manufacturing defects
Full technical support: Pre-sales selection, in-sales progress updates, after-sales installation assistance
24-hour response : English-speaking sales and technical team
5. Packaging & Shipping
Standard export wooden cases (fumigation-free)
Plastic cap protection on flange faces and stem threads
Mixed container loading available (gate valves can be shipped together with butterfly valves, check valves, etc.)
|
Feature |
Rising Stem Gate Valve (Our Product) |
Non-Rising Stem Gate Valve |
|
Visual indication of open/close |
Yes – stem rises |
No |
|
Suitable for buried pipelines |
No |
Yes |
|
Maintenance convenience |
Easy to check seal |
Requires disassembly |
|
Recommended application |
Above-ground water/gas lines |
Space-limited or buried applications |
Important Reminder: Resilient seat gate valves must NOT be used for throttling. Partially open conditions will cause rapid erosion of the resilient sealing surface, especially with particle-laden media. Please use fully open or fully closed only.
We regularly participate in major industry exhibitions worldwide. Come see our rising stem resilient seat gate valves in person and discuss your project needs with our team.
Vietwater 2025 (Oct 22-24, Ho Chi Minh City, Vietnam) – Booth I06
Asiawater 2026 (April, Kuala Lumpur, Malaysia)
Contact us in advance to schedule a meeting at the show.
