Introduction
Ball valves are everywhere—in your home, your workplace, and nearly every industrial plant or pipeline system you can think of. But unless you’re in the field, you might not realize how essential these simple-looking components really are.
So what is a ball valve used for? That’s what this guide will break down clearly, with no jargon and no fluff.
What Is a Ball Valve and How Does It Work?
A ball valve is a type of shut-off valve that controls the flow of liquids or gases through a pipeline using a rotating ball with a central bore. When the ball is aligned with the flow path, fluid passes through freely. When rotated 90 degrees, the solid part of the ball blocks the flow completely.
Key Characteristics:
Quarter-turn operation: Rotating the handle 90° opens or closes the valve
Tight sealing: Especially in low-pressure or clean fluid systems
Minimal pressure drop: Unlike globe or needle valves, the flow path is almost straight
Durable and low-maintenance: Often used for infrequent on/off operations
Ball valves come in various body styles (one-piece, two-piece, three-piece), but the core mechanism remains the same: a precision-drilled ball rotates inside a valve body to allow or stop flow.
Cutaway diagram showing how the ball inside a valve controls liquid or gas flow
Common Uses of Ball Valves
Ball valves are valued for their simplicity, durability, and fast shut-off capability—which makes them useful in a wide range of systems and industries. Below are the most common functions they serve in real-world applications.
1. Shut-Off / Isolation
This is the most common use for a ball valve.
Ball valves are installed in pipelines to completely stop flow when necessary.
They’re perfect for maintenance operations or emergency stop situations where a system must be shut off instantly.
Example: A ball valve placed just after a water meter to isolate the house’s internal piping.
2. Emergency Safety Control
In critical systems like gas lines or industrial fluid circuits, ball valves can be used as emergency shut-offs.
Their fast quarter-turn operation is ideal when time matters.
Example: Ball valves in fuel or chemical systems designed to be closed manually or remotely in case of leaks.
3. Flow Diverging / Switching (3-Way Ball Valves)
Multi-port ball valves (e.g., 3-way or 4-way) are used to redirect flow from one pipeline to another.
Great for fluid distribution networks where flow direction changes are needed.
Example: Switching between two tanks in a liquid processing plant using a single valve body.
4. Draining or Purging
Ball valves are used at the lowest point in a system to drain fluids, purge air, or evacuate residue.
They’re commonly found in boilers, tanks, and air compressor systems.
Example: A small brass ball valve at the bottom of a compressed air tank to release accumulated moisture.
5. Limited Throttling (With Caution)
Ball valves can be used to regulate flow partially, but they’re not ideal for precision throttling.
If left partially open for long periods, turbulence and wear may occur on the ball and seats.
